LoRa & LoRaWAN gateways

LPWAN gateways and concentrator modules are intermediaries that allow sensing devices to transmit data to the IoT cloud.

Source: https://store.rakwireless.com/collections/lpwan-gateways-concentrators

1

Boost the growth of cost-effective community established LoRaWAN Gateway

LoRaWAN leading for remotely-deployed applications that require long-range or deep in-building communication between a large number of devices that have low power requirements and collect low or sporadic amounts of data. Ready to start with LoRa as a systematize LPWAN Gateway, LoRa transceivers utilize worldwide unlicensed spectrum such as those in the 433/470/868/780/915 MHz ISM bands, which is more profitable to develop and deploy assets into than the global LTE bands and experiences less interference compared to Wi-Fi (which operates at 2.4GHz and 5GHz). Get many advanced and well-integrated LoRa gateways capable of simultaneous reception on several channels and implementing the LoRaWAN specification.

RAKwireless Store

An amazing collection of LoRaWAN™ products RAKwireless offers: LoRaWAN™ Gateways / Concentrators, LoRa® Modules, LoRa® Boards / Nodes, NB-IoT Boards, PLC Modules, LoRa® Antennas / Connectors. Check them out today!

RAK7246G & RAK7246 Blue is the New Black LoRaWAN™ Developer Gateway

The RAK7246 is a LoRaWAN™ Developer gateway is the model without the GPS function. It is a device composed of a the RAK2246 Pi HAT LoRaWAN™ Concentrator modu...

Connecting RAKwireless Commercial Gateways to the Cloud

Amazon offers a free cloud service (aws.amazon.com); you only need to make an Amazon account. There is a limit however: 750 hours per month for a period of 12 months

Installation Guide for DIY Enterprise LoRa Gateway

The MainBoard supports multiple variants for meeting different requirement. Please refer to the DIY configuration for supported function.

Be One Step Ahead With MQTT Bridge: Its Advantages vs a UDP Packet Forwarder

We can go faster and even more secure with our communication. Advanced network protocols in IoT are then born, specifically MQTT.

RAK7246 LPWAN Developer Gateway

The RAK7246G is a LoRaWAN™ Developer gateway with GPS function. It is a device composed of a the RAK2246 Pi HAT LoRaWAN™ Concentrator module and Raspberry Pi Zero W. The RAK2246 Pi HAT is based on a Semtech SX1308 chip, which allows for simultaneous reception over 8 LoRa channels, which cover the entirety of the international high-frequency LoRaWAN™ space. The RAK7246G is an ideal choice for prototype design, concept verification and demonstrations, development evaluation and other scenarios. It is developer-friendly due to its minimalistic design that reduces cost and allows for easily accessing the internals. It is easy to set-up, which makes it a good choice for both experienced and novice LoRa specialists. #RAK7246 The RAK7246 is a LoRaWAN™ Developer gateway is the model without the GPS function. It is a device composed of a the RAK2246 Pi HAT LoRaWAN™ Concentrator module and Raspberry Pi Zero W. The RAK2246 Pi HAT is based on a Semtech SX1308 chip, which allows for simultaneous reception over 8 LoRa channels, which cover the entirety of the international high-frequency LoRaWAN™ space. The RAK7246 is an ideal choice for prototype design, concept verification and demonstrations, development evaluation and other scenarios. It is developer-friendly due to its minimalistic design that reduces cost and allows for easily accessing the internals. It is easy to set-up, which makes it a good choice for both experienced and novice LoRa specialists. Key Features Using SX1308 baseband processor, full 8 uplink channels and 1 downlink channel LoRaWAN™ Gateway; Built-in Ublox MAX-7Q GPS module; The Pre-installed radiator guarantees the stable thermal performance Tx max 20dbm, Rx min -139dbm @ SF12 at 125kHz; Covers the entirety of the LoRa high-frequency band space: RU864, IN865, EU868, US915, AU915, KR920, AS923; Power supply 5V / 2.5A (included adapter). #RAK7246 Key Features Using SX1308 baseband processor, full 8 uplink channels and 1 downlink channel LoRaWAN™ Gateway; The Pre-installed radiator guarantees the stable thermal performance Tx max 20dbm, Rx min -139dbm @ SF12 at 125kHz; Covers the entirety of the LoRa high-frequency band space: RU864, IN865, EU868, US915, AU915, KR920, AS923; Power supply 5V / 2.5A (included adapter). #all Package Details Product Dimensions: 96mm x 66mm x 47mm Enclosure Material: Acrylic Ingress Protection Rating: IP30

RAK7258 Micro Gateway

The  supports LoRa MQTT Bridge mode, with the option for TLS authentication. You can now buy LoRa gateway that a built-in LoRa packet forwarder and a graphical user interface, allowing for a quick set-up. Want to know more?

RAK7244 LPWAN Developer Gateway

The is a device that consists of a Raspberry Pi 4, a RAK2245 Pi HAT, which includes a GPS module and a Heat Sink for better performance and thermal heat dissipation management, and an optional RAK2013 Cellular Pi HAT. Its housing is entirely built from aluminum. The built-in RAK2245 Pi HAT uses the SX1301 RF front-end chip from Semtech, which is a powerful LoRa digital processing engine. It is able to receive up to 8 LoRa packets simultaneously sent with different spreading factors on different channels and available in multiple variants so it can be used for all LoRa Allience™ frequency bands. This unique capability allows for innovative network architectures to be implemented, which is advantageous over other short-range systems. The built-in RAK2013 Cellular Pi HAT is based on the EG95 from Quectel, which is an LTE CAT4 module optimized specifically for M2M and IoT applications. The RAK7244 LPWAN Developer Gateway is ideal for prototyping, proof-of-concept demonstrations or for the evaluation of future deployment scenarios. It includes a ready to use Firmware based on Raspbian OS, which makes it possible to connect the Gateway to any standard LoRaWAN Server. It is developer-friendly as the large Raspbian OS community is a well-established one. It is especially suited to addressing a variety of applications like Smart Grids, Intelligent Farms, and other IoT Enterprise applications. Complete documentation of this product can be found on our website documentation page. To know the difference between EG95-E and EG95-NA, please refer to the following table: Frequency EG95-E EG95-NA LTE FDD B1/B3/B7/B8/B20/B28A B2/B4/B5/B12/B13 WCDMA B1/B8 B2/B4/B5 GSM/EDGE B3/B8 Region EMEA North America Carrier Certification Verizon/ AT&T/ T-Mobile/ Telus/ U.S. Cellular/ Rogers Regulatory Certification GCF/ CE/ RCM/ FAC GCF/ FCC/ PTCRB/ IC Other Certifications WHQL WHQL Key Features Refreshed Case design with a new MCU (Raspberry Pi4) Preassembled, fully functioning developer LoRaWAN™ Gateway Full LoRaWAN™ Stack support (version 1.0.2) Supports for 8 channels and spreading factors (SF7-SF12) Band support: 433MHz, 470MHz, 865MHz, 868MHz, 915MHz, 920MHz, 923MHz Tx Power: 27 dBm Max RX Sensitivity: -139dBm Integrates Ublox MAX-7Q GPS module Quectel EG95 LTE module Package Contents non-LTE Variant 1unit RAK7244 Developer LoRaWAN™ Gateway 1pc LoRa Antenna 1pc GPS Antenna 1pc Power Adaptor 1pc SD Card LTE Variant 1unit RAK7244C Developer LoRaWAN™ Gateway 2x LTE Antenna 1pc LoRa Antenna 1pc GPS Antenna 1pc Power Adaptor 1pc SD Card Package Details Product Dimensions: 50mm x 90mm x 90mm Product Weight: 6kg

RAK7243 LPWAN Developer Gateway

Looking for a device that will help you to successfully deploy cloud gateway? You may need to see this! The RAK7243C is a fully fledged 8-channel LoRaWAN Gateway. You can use the device for various small and large scale projects, including indoor and outdoor cloud deployment. It also gives you cellular backhaul plus Wi-Fi and Ethernet of the Raspberry Pi 3B+. You can view more about the device on RAKwireless store

RAK7249 Macro Outdoor Gateway

We bring to you the best DIY solutions. Our multichannel LoRaWAN gateways will definitely serve your DIY purposes. This DIY 8 channel LoRa gateway device is the right choice for you. To know more about its specifications check here.

LoRaWAN™ vs. the world of IoT!

How does our favourite stacks up agains the old and new contenders for the krown of IoT king?

Shenzhen RAKwireless Technology Co., Ltd.

RAK7240 Outdoor LPWAN Gateway, Network configure the protocol to be used in connecting to your provider's network. https://doc.rakwireless.com/rak7240-outdoor-lpwan-gateway/network-configuration

LoRaWAN, Two, Three, and More! The Future of Combined and Individual Protocols

The Internet of Things and the people who play in it are significantly increasing day by day. By 2020, the number of IoT devices is even expected to r
